OMAX 40X-2000X Trinocular Phase Contrast Compound LED

• 5MP (2592x1944 pixels) color digital camera with 0.5X reduction lens and 0.01mm calibration slide
• Phase contrast microscope for viewing live cell cycle, no staining required to view the slide
• Four phase contrast lenses and one bright field Abbe condenser on one disk, fast and easy to switch, no condenser change needed
• Large double layer mechanical stage and coaxial coarse & fine focus knobs
• Replaceable 3W LED transmitted light with adjustable intensity

This trinocular compound microscope provides USB digital imaging system and phase contrast/brightfield microscope system. The compound microscope features an optical system for simultaneously observing images through eyepieces and an adjustable trinocular port. It comes with LED illumination with variable intensity, Abbe NA1.25 condenser with iris diaphragm, 5MP digital camera and a complete set of phase contrast kit. The 2592x1944 pixels USB digital imaging system that captures still microscope images and live video on computer. The included software is compatible with Windows, Mac OS X and Linux operating systems (see version information below). The Windows software can also be used to make measurements. It offers eight levels of brightfield magnification from 40X to 2000X. The phase contrast kit includes a phase contrast condenser, a centering telescopic eyepiece, four phase contrast objectives: PH10X, PH20X, PH40X (S), PH100X (S, Oil). It also offers magnification power: 100X-200X-400X-800X-1000X-2000X. This phase contrast compound microscopy is widely used clinical, biological research and schools, specially for observing live cells.

• Model: M837SL-PHB3-C50U
• Total magnification for brightfield: 40X-80X-100X-200X-400X-800X-1000X-2000X
• Total magnification for phase contrast: 100X-200X-400X-800X-1000X-2000X
• Eyepieces: widefield WF10X/18 and WF20X
• Brightfield objectives: achromatic DIN 4X, 10X, 40X (S), 100X (S, Oil)
• Phase contrast objectives (in phase contrast kit): PH10X, PH20X, PH40X (S), PH100X (S, Oil)
• Viewing head: 45°Inclined 360°swiveling trinocular
• Interpupillary distance: sliding adjustable 2-3/16" ~ 2-15/16" (55mm ~ 75mm)
• Diopter: adjustable on both eyepiece tubes
• Nosepiece: revolving quadruple
• Stage: mechanical stain-resistant double layer, size: 5-1/2" x 5-1/2" (140mm x 140mm), translation range: 3" x 2" (75mm x 50mm)
• Photo tube adjustment range: 5/8" (15mm)
• Focus: coaxial coarse and fine focus knobs on both sides, rack & pinion adjustment, with tension control
• Focusing knob can be locked for observation & transportation
• Condenser & diaphragm: Abbe NA1.25 rack & pinion adjustment condenser with iris aperture diaphragm
• Phase contrast kit:
  - Substage phase contrast condenser disk with five switchable positions:
  - One bright field NA1.25 with iris diaphragm Abbe condenser
  - Four phase contrast condensers: 10X, 20X, 40X, 100X
  - Each phase contrast condenser can be centered individually
  - Four PH objectives: 10X, 20X, 40X (S), 100X (S, Oil)
  - 37mm mounting size in diameter
  - Centering telescope: 23.2mm
• Black palm rest on the base
• Illumination: transmitted (lower), replaceable 3W LED light, variable intensity
• Metal mechanical components
• Power supply: 100V~240V 50/60Hz worldwide range (US and Canada power plug)
• Digital camera:
  - true color 2592x1944 pixels (5M pixels)
  - 0.5X reduction lens to get larger field of view
  - 0.01 mm calibration slide: 1mm/100 division
  - Frame speed: 5fps at 2592x1944, 18fps at 1280x960, 60fps at 640x480
  - Software compatible with Windows, Mac OS X and Linux operating systems
  - Capturing microscope images, recording live video, measuring lengths, angles, areas, editing images
  - USB 2.0 cable included
• Dimension of microscope: 7-7/8 " x 10-1/4" x 16" (20cm x 26cm x 41cm)
• Dimension of phase contrast kit: 12" x 9" x 5-11/16" (30.5cm x 23cm x 14.5cm)
• Shipping packages: 15 lbs (7 kg) & 5 lbs (2 kg)

Software:

Please check the chart below for computer operating system compatibility

• Trinocular microscope head
• Microscope stand
• Photo tube
• 4 objectives: 4X, 10X, 40X, 100X
• A pair of eyepieces WF10X/18
• A pair of eyepieces WF20X
• A bottle of immersion oil
• Power cord (US and Canada standard)
• Mirror for power outage
• Dust cover
• Color filter
• Extra fuse
• 1 centering telescopic eyepiece
• 4 phase contrast objectives: 10X, 20X, 40X, and 100X
• 1 condenser disk with bright field condenser and 4 phase contrast filters
• 1 green filter
• 1 screw driver
• 1 aluminum phase contrast storage box
• 5MP digital camera
• 0.5X reduction lens
• 1 CD including driver, software and user's instruction
• 0.01mm calibration slide (stage micrometer)
• USB cable

• Other phase contrast kits
• Darkfield kits
• 16X eyepieces
• Carrying case
• Other USB digital cameras
• Temperature controlled add-on stage
• Prepared slides
• Blank slides
• Plastic slide storage box
• Glass slide cover
• UK power plug adapter
• Lens cleaning paper
